High-efficiency clarification glass fiber membrane filter cartridge

High-efficiency clarification glass fiber membrane filter cartridge

Eternalwater EBG Series--Glass fiber membrane filter cartridge, GF membrane is made of 100% borosilicate ultrafine glass fiber, capillary fiber structure, non-hygroscopic and biologically inert. Suitable for gas pre-filtration, liquid filtration containing colloid, oil and protein materials.
  • Product features
  • High porosity, high dirt holding capacity
    High flow rate, low pressure drop
    Long-life, economical pre-filtration
    With adsorption, high filtration efficiency
  • Industry Application
  • Filtration of compressed air of degreasing and removing particle.
    Air pre-filtration of bio-engineering fermentation
    Filtration of cell culture media and buffer solution
    Pre-filtration of serum and blood products
    Clarification and filtration of highly viscous, colloidal liquids
  • DOWNLOAD
  • INQUIRY NOW
PRODUCT DESCRIPTION
  • Filter Material:
  • Glass Fiber Membrane (GF)
  • Center core / Housing / End cap Material:
  • Polypropylene
  • Cage material:
  • Polypropylene
  • Vent O-ring Material:
  • Silicone/ EPDM/ Viton
  • Filtration area:
  • ≥0.4m²/10inch
  • Maximum working temperature:
  • 80℃
  • Maximum working:
  • 4.2bar@23℃（forward direction)
  • pressure difference:
  • 2.4bar@80℃（forward direction）
  • Sterilization:
  • 126℃/30min； high pressure steam sterilization；≥30 times
  • Endotoxin:
  • ＜0.25EU/mL
  • Extractable matter:
  • ＜30mg/10inch
  • Biocompatibility:
  • All materials comply with biosafety evaluation of plastic USP<88>, ClassVI-70°C level
Ordering Information
  • Series
  • EBG Series
  • Micron Rating
  • 045=0.45μm
  • 065=0.65μm
  • 100=1.00μm
  • 500=5.00μm
  • End cap type
  • J1=222/Fin
  • J2=222/Flat
  • J3=226/Fin
  • J4=226/Flat
  • J5=DOE
  • Length
  • 05=5"
  • 10=10"
  • 20=20"
  • 30=30"
  • 40=40"
  • O-ring
  • S=Silicone
  • E=EPDM
  • V=Viton
  • core
  • A=PP core
  • B=PP Cage material + End cap type lined with stainless steel
  • C=PP Cage material + stainless steel lining
